Мультиметры

Technical data Range 0.3~40m/60m/80m Smallest unit displayed 1mm Measuring accuracy ±1.5mm Laser class 2 Laser type 635nm<1 mW Battery life: Type AA, 2х1.5V up to 5000 measurements Dimension 124(L)х49(W)х27(H) mm Auto laser switch-off 30s Auto instrumentswitch-off 180s Temperature range 0~40*C Operation storage -10~60*C General description Power supply 3V (1.5V*2pcs) Included accessor...

Technical data Function Range KJ9802 DC Voltage 200mV/2V/20V/200V/1000V ±(0.5%+3) AC Voltage 200mV/2V/20V/200V/750V (200mV range for KJ9801 only) ±(1.0%+3) DC Current 200uA/2mA/20mA/200mA/10A (200uA/2mA range for KJ9801 only) ±(0.8%+8) AC Current 2mA/200mA/10A (2mA range for KJ9801only) ±(1.0%+8) Resistance 200O/2kO/20kO/2MO/20MO/200MO ±(1.0%+2) Capacitance 2nF/20nF/200nF/2µF/200µF ±(4.0...

Technical data Function Range KJ208 DC voltage 200mV/2V/20V/200V/600V ±(0.5%+4) AC voltage 200mV/2V/20V/200V/600V ±(1.0%+6) DC current 20A/200A/500A ±(2.5%+8) AC current 200µA/2mA/20mA/200mA ±(1.2%+8) Resistance 200O/20mO ±(1.2%+2) Capacitance 200µF/2000µF ±(3.0%+15) Diode test v Continuity v Auto power off v Data hold v Low battery indication v Backlight display v Unit symbol display v ...

Technical data Function Range Basic accuracy KJ9205 DC Voltage 200mV~1000V ±(0.5%+3) AC Voltage 200mV~750V ±(1.0%+3) DC Current 200mA~10A ±(0.8%+3) AC Current 2mA~10A ±(1.8%+3) Resistance 200O~200mO ±(1.0%+3) Continuity test Beeps at 30O or below Capacitance 2nF~200µF ±(4.0%+3) Diode test Display HFE Ib = 10uA Vce< 3V Frequency 200Hz~20kHz х Temperature test -40 *C~1000 *C х General d...

Technical data Function Range Basic Accuracy DCV 4V, 40V, 400V, 1,000V ± (0.05% + 4) ACV 400mV, 4V, 40V, 400V, 750V ± (0.8% + 8) DCµA 400µA, 4,000µA ± (1.2% + 3) ACµA 400µA, 4,000µA ± (1.0% + 6) DCmA 40mA, 400mA ± (1.2% + 3) ACmA 40mA, 400mA ± (1.0% + 6) DCA 4A, 10A ± (1.2% + 10) ACA 4A, 10A ± (2.0% + 15) Resistance 400O, 4kO, 40kO, 400kO, 4MO,40MO ± (1.0% + 3) Capacitance 50nF, 500nF, 5...

Technical data Function Range Basic accuracy DC Voltage 200mV/2mV/20mV/200V/600V ±(0.6%+1) AC Voltage 200V/600V ±(2.0%+8) DC Current 200uA/2mA/20mA/200mA/10A ±(2.0%+8) Resistance 200O/2kO/20kO/200kO/2mO ±(1.5%+8) Diode test v Continuity v Data hold v Low battery indication v Back Light display v Unit symbol display v General description Power supply 9V battery LCD size 49х20mm Accessorie...

Technical data Function Range Basic accuracy KJ39E DC Voltage 200mV/2V/20V/200V/600V ±(0.5%+1) 400mV/4V/40V/400V/600V х AC Voltage 200V/600V ±(1.2%+5) 400mV/4V/40V/400V/600V х DC Current 2mA/20mA/200mA/10A ±(1.8%+3) 400µA/4000µA/40mA/400mA/4A/10A х AC Current 400µA/4000µA/40mA/400mA/4A/10A х Resistance 200O/2kO/20 kO/200kO/20mO х Temperature -40*C ~400*C /-40°F ~1832°F х Battery test х S...

Technical data Function Range Basic accuracy DC Voltage 200mV/2V/20V/200V/1000V ±(0.05%+3) AC Voltage 2V/20V/200V/750V ±(1.0%+2) DC Current 2mA/200mA/10A ±(1.0%+2) AC Current 2mA/200mA/10A ±(1.5%+2) Resistance 200O/2kO/20kO/200kO/2MO/20MO/200MO ±(1.0%+2) Capacitance 20nF/200nF/2µF/20µF/200µF ±(3.0%+2) Frequency 20kHz ±(0.5%+2) Diode test v HFE v Continuity v Data hold v Manual range v In...

Line Scanning: v Line Testing: v Lighting Flashlight: v Adjustable Tone: v LED Indicators: v Transmission Distance: ? 3km Output Signal Level 25Vp-p
